HPCN Slotted 50PIN Straight Plug SCSI Socket

Brand UNIKOON Model SCSI5-502-05-1 Category Plugs / sockets
Number of poles 50 Rated current 5A Voltage 2.5V (V)
Operating Frequency Low Frequency Color Black Application
Interface Type IDC Shape Bar Length 0 (mm)
Production process Cold press processing Customization is the characteristic moisture-proof
Contact material H65 insulator material PBT core number 50
Pin number 50 Order number 0 Material number SCSI5-502-05-1
The minimum number of packages is 100

Material:

      1 colloid: PBT, UL94V-0

  2 terminals: copper alloy
  3 Coating: according to the requirements set

ELECTRICAL CHARACTERISTICS:
1 Rated current: 5A
2 Withstanding voltage: 1000Vr.m.s, 1mA, 60s
3 Insulation resistance: ≥ 2000MΩ
4 Contact resistance: ≤ 25mΩ

Mechanical properties:
Insertion force: ≤2.0N / pin
2 Pull-out force: ≥ 0.3N / pin

3 overall insertion force: ≤ 30N
4 Overall pulling force: 3.3N ~ 20N

5 life times: 500 times


Operating temperature:
  -40 ° C to + 100 ° C

  Features:
     Mainly applicable to communications and electronic data processing equipment and use
Similar to an electronic device or device. Frequency less than 3MHz, the product
In line with IEC60807 international standards, with similar products at home and abroad exchange
