Technical Parameters:
Lines: 2,3,4,5,6,8,10,12,
        14,16,18,20,22,24
Applicable wire: AWG28 # ~ 22 #
Applicable substrate thickness: 1.6mm
Temperature range: -25 ℃ ~ + 85 ℃
Rated voltage: 250V
AC / DC
Current Rating: 5A
Contact resistance: ≤0.015Ω
Insulation resistance: ≥1000MΩ
Withstand voltage: 1500V AC / 1 Fenzhong

material:
Plug: Nylon UL94V-2
Socket: Nylon UL94V-2

Terminals: Phosphor bronze
