Technical Parameters:
Lines: 2,3,4,5,6,8,10,12,
14,16,18,20,22,24
Applicable wire: AWG28 # ~ 22 #
Applicable substrate thickness: 1.6mm
Temperature range: -40 鈩 ~ + 105 鈩
Rated voltage: 250V
AC / DC
Current Rating: 9A
Contact resistance: 鈮0.015惟
Insulation resistance: 鈮1500M惟
Withstand voltage: 1500V AC / 1 Fenzhong
material:
Plug: Nylon UL94V-2
Socket: Nylon UL94V-2
Terminals: Phosphor bronze
