Technical Parameters:
Spacing: 2.5
Applicable wire: AWG # 30 ~ # 22
Rated voltage: 250V
DC / AC (RMS)
Current Rating: 3.0A
Withstand voltage: 1000V AC
(RMS)
Operating temperature: -25 ℃ ~ + 85 ℃
Insulation resistance: ≥1000MΩ
Contact resistance: ≤0.02Ω
Applicable PC board thickness: 1.6mm

material:
Housing: Nylon 66 UL94V-0
Needle seat:
1. Housing: Nylon 66 UL94V-0
2. Pin: Brass
Terminals: Phosphor bronze
