Technical Parameters:
Line: 2 to 16
Applicable wire: AWG # 32 ~ # 28
Rated voltage: 125V DC / AC (RMS)
Current Rating: 1.0A
AC / DC
Withstand voltage: 500V AC (rms)
Operating temperature: -25 鈩 ~ + 85 鈩
Insulation resistance: 鈮500M惟
Contact resistance: 鈮0.01惟
material:
Pin: Brass
Terminals: Phosphor bronze
Block A: Nylon 66 UL94V-0
Y Block: PBT reinforced nylon 66
