1.25mm pitch female socket PCB board connector

Technical Parameters:
Line: 2 to 16
Applicable wire: AWG # 32 ~ # 28
Rated voltage: 125V DC / AC (RMS)
Current Rating: 1.0A
Withstand voltage: 500V AC (rms)
Operating temperature: -25 ℃ ~ + 85 ℃
Insulation resistance: ≥1000MΩ
Contact resistance: ≤0.02Ω

material:
Housing: PBT reinforced nylon 66
Pin: phosphor bronze
Terminals: Phosphor bronze
Block A: PBT
